True Zero-Tail Swing Design
Allows the machine to rotate within its own footprint, improving manoeuvrability, safety and productivity in restricted working environments.
UK-wide delivery — delivery direct to your site
Hyundai Construction Equipment
HX25A Z
Zero tail swing agility, easy transport and versatile attachment capability make the HX25A Z a practical, productive choice for fast-moving compact excavation work.
In stockFinance available2yr warranty
Price
POA
Compact Excavators
The Hyundai HX25A Z is built to move easily between jobs and work confidently once it gets there. Its compact zero tail swing design makes confined spaces easier to manage, helps reduce the risk of contact with nearby obstacles and supports quick loading and transport for contractors working across multiple sites.
Flexible attachment capability, intuitive controls and a comfortable operator environment help crews switch efficiently between digging, grading and support tasks. Easy service access and Hyundai’s remote machine-management capability are designed to simplify maintenance planning, reduce downtime and keep the machine available for productive work.
Powerful Stage V Performance
The Kubota D1305 engine delivers 24.8 hp (18.5 kW) gross power while meeting EU Stage V emissions standards without additional exhaust after-treatment systems.
Attachment Ready
Standard two-way auxiliary piping and optional hydraulic quick coupler piping allow fast attachment changes to suit a wide range of applications.
Operator Comfort & Control
A spacious high-visibility cab, 5-inch colour LCD display, auto-shift travel speed and ergonomic controls provide improved comfort and efficiency throughout the working day.
Technical Specifications
Full specification for the Hyundai HX25A Z compact excavator. Download the full datasheet for complete technical drawings and dimensional data.
Machine weights & dimensions
Operating Weight2,685 kg
Machine Width1,534 mm
Machine Height2,452 mm
Machine Length4,150 mm
Tail Swing RadiusZero Tail Swing Radius
Ground Clearance183 mm
Engine
Engine MakeKubota
Rated Power18.5 kW
Travel Speed4.35 / 2.38
Displacement1,261 cc
Fuel Tank Capacity30 L
Emissions StandardEU Stage V
Digging performance
Max Digging Depth2,515 mm
Max Reach at Ground4,420 mm
Max Vertical Wall Depth1,970 mm
Max Digging Height4,175 mm
Max Dump Height2,870 mm
Bucket Capacity0.06 m³
Hydraulics & travel
Pump TypeVariable displacement tandem axis piston pumps
Maximum Hydraulic Pressure220 kgf/cm²
Maximum Hydraulic Flow2 × 28.2 + 20 L/min
Auxiliary Hydraulic Flow48 L/min (2-way)
Travel Speed4.35 / 2.38 km/h (High/Low)
Traction Force2,266 kg
Swing Speed9.16 rpm
Hydraulic Tank Capacity27 L
Download full datasheet
Complete dimensional drawings, load charts and full technical specification PDF
Finance & Leasing Options
Spread the cost of your HX25A Z with flexible financing through Rygor Plant. All options are subject to status and financial check.
0% Finance for 36 months*
POA
0% APR · 10% Deposit required · 36 months · You own the machine at the end
- Hyundai A Series Mini Excavator Range
- 1 to 8.5 tonnes
- While stocks last
- Offer ends 30th September 2026
Finance lease
POA
Indicative rates on request · Term flexible 24–60 months · Machine treated as off balance sheet
- Lower monthly payments than HP in some cases
- Flexible end-of-term options
- Option to extend, return or buy at end of term
- Rentals fully tax deductible
Finance is subject to status and financial check. Rygor Plant acts as a credit broker, not a lender. Finance is provided by third-party lenders. The representative APR of 1.9% is based on a specific example and your rate may differ. All finance is subject to eligibility. Terms and conditions apply.
Aftersales, Service & Parts
Your relationship with Rygor Plant doesn't end at delivery. We're with you for the life of your machine.
Planned maintenance
Scheduled service plans keep your HX25A Z at peak performance and maintain warranty coverage throughout its life.
Book a serviceBreakdown assistance
Machine down on site? Our mobile engineers operate across the UK and can be dispatched fast to minimise your downtime.
Call nowGenuine OEM parts
Genuine Hyundai parts sourced directly from the OEM. Same-day or next-day dispatch from our parts hubs.
Order parts onlineEnquire About This Machine
Interested in HX25A Z? Complete the form and one of our plant specialists will contact you with pricing, availability and finance options.
